Nylatron ™ The characteristic of 66 SA PA66 AE unmodified nylon is that it combines excellent strength and toughness. Compared to other unmodified nylon grade materials, Nylatron ™ 66 SA PA66 AE has excellent mechanical strength, stiffness, and wear resistance. Due to these properties and compliance with FDA 21 CFR § 177.1500 standards, Nylatron ™ 66 SA PA66 AE is commonly designated for use in threaded cutting of electrical insulators, bushings, bearings, gears, rollers, star wheels, and seals, particularly in aerospace applications.
Performance
- Excellent combination of mechanical strength and toughness
- Good wear resistance
- Meets the requirements of FDA 21 CFR § 177.1500 standard
| Performance |
Value |
| Heat Deflection Temperature at 1.8MPa (264 psi) (ºC) |
85 |
| Continuous allowable service temperature in air |
80 |
| Flammability (UL Rating) |
HB |
| Performance |
Value |
| Tensile Strength (MPa) |
90 |
| Tensile Modulus of Elasticity (MPa) |
3,550 |
| Compressive stress at 1% nominal strain (MPa) |
32 |
| Compressive stress at 2% nominal strain (MPa) |
62 |
| Compressive stress at 5% nominal strain (MPa) |
100 |
| Flexural Strength (MPa) |
135 |
| Charpy Impact Notched (kJ/m²) |
4.5 |
| Performance |
Value |
| Hot Water / Steam |
Limited |
| Acids, Weak |
Limited |
| Acids, Strong (pH 1-3) |
Not acceptable |
| Alkalies, Weak |
Limited |
| Alkalies, Strong (pH 11-14) |
Not acceptable |
| Hydrocarbons - Aromatic |
Acceptable |
| Hydrocarbons - Aliphatic |
Acceptable |
| Ketones, Esters |
Acceptable |
| Chlorinated Solvents |
Limited |
| Alcohols |
Limited |
| Inorganic Salt Solutions |
Acceptable |
| Performance |
Value |
| Dielectric Strength (kV/mm) |
27 |
Industry Specific Usage (FOOD)
| Performance |
Value |
| FDA |
Compliant |
| EU |
Not compliant |
| USDA |
Not compliant |
| 3A-SSI |
Not compliant |
| VMX materials |
Not compliant |
Industry Specific Usage (MEDICAL)
| Performance |
Value |
| ISO 10993-5 and USP <87> |
Not compliant |
| ISO 10993-10 Sensitization |
Not compliant |
| ISO 10993-10 (Intracutaneous Reactivity) and USP <88> |
Not compliant |
| ISO 10993-11 and USP <88> |
Not compliant |
| USP <88> (Implant) |
Not compliant |
| ISO-10993-4 |
Not compliant |
| USP <661> |
Not compliant |
| USP Class VI |
Not compliant |
| AFO - Animal Free Origin |
Not compliant |
Industry Specific Usage (RECYCLED)
| Performance |
Value |
| Statera™ portfolio |
Not compliant |
Industry Specific Usage (NUCLEAR)
| Performance |
Value |
| Shielding Portfolio |
Not compliant |
| PMUC certified |
Not compliant |
Industry Specific Usage (SEMICON)
| Performance |
Value |
| ESd materials |
Not compliant |
| Conductive materials |
Not compliant |
| Performance |
Value |
| Base Material |
PA66 |
| Brand Family |
|
| Colors |
黑色 白色 |
| Density (g/cm3) |
1.14 |
| Water Absorption after 24 hrs immersion in water (%) |
0.60 |
| Water Absorption at saturation in water (%) |
8 |
| Wear Factor (µm/km) |
14 |
| Available shapes |
板 棒 |
| Main Use Bearing and/or Structural |
Bearing Structural |
